PIPE-MIC II Pipe Invert Measurement Solution w/ Zero and 1ft Vertical Offset Positions


Product Description

PIPE-MIC II:    Instruction Sheet

Measure pipe inverts and sizes fast, easy & accurate

  • Measurements are more accurate because you are measuring with a ​vertical plumb rod
  • Made for Crain 25' SVR
  • Made of lightweight (two pounds) non rusting aircraft aluminum
  • No tools needed​​ to attach to rodSlides on and off in seconds
  • Round foot design slices through material at bottom of pipe and ​insures accurate invert and pipe diameter measurement.

By pulling a pin in just seconds you can go from zero to 1 ft. vertical offset for clearance under rod

To use:
* You can direct read the depth of the invert when the pin is set at "zero offset" on the PIPE-MIC II
* If you need clearance under rod to measure an invert move the pin to "1' vertical ​​offset hole"
* If you need clearance under rod and a pipe that is hard to reach you can add a 1 ft. extension
   (1 ft. extension sold separately) Move pin to " 1' vertical offset w/ 1' extension" hole

To size a pipe:
The foot is 0.33 or 4". Take the reading from the rim, pull up and take reading plus 0.33 and that is your pipe size
